Keysight N9038A - Intermittent, Unsteady, Drifting Disturbances

Keysight N9038A MXE Service Guide 755
Tests
Intermittent, Unsteady, Drifting Disturbances
Intermittent, Unsteady, Drifting Disturbances
Test Limits
See test limits in test results Table 22-71 and Table 22-72.
Overview
This test will verify the response of the EMI Average and RMS Average
detectors of the EMI receiver according to CISPR 16-1-1 :2010 standard to
intermittent, unsteady, and drifting narrowband disturbances. This includes
testing for the following subsections:
6.5.4 Response to intermittent, unsteady, and drifting narrowband
disturbances
7.5.4 Response to intermittent, unsteady, and drifting narrowband
disturbances
Table 22-70 Intermittent, Unsteady, Drifting Disturbances - Required Equipment
Item
Critical Specifications
(for this test)
Recommended
Keysight Model
Adapter
a
Type-N (m) to 3.5 mm (f)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.1:1
1250-1744
Adapter
b
3.5 mm (f) to 3.5 mm (f)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.1:1
83059B
Adapter
c
2.4 mm (f) to 3.5 mm (f)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.1:1
11901B
Cable, 1 meter
3.5 mm (m) to 3.5 mm (m)
Frequency: 10 kHz to 1.51 GHz
VSWR: < 1.4:1
11500E
Signal Generator Frequency Range: 100 kHz to 1.5 GHz
Amplitude Range: -40 to 0 dBm
Narrow Pulse Modulation
PSG w/Option UNW
a. Quantity 2 required for Option CNF (Type-N RF Input)
b. Only required for Option C35 (3.5 mm RF Input)
c. Only required for Option 544 (44 GHz Frequency Range)
