Keysight N9038A MXE Service Guide 723
Tests
Peak Detector Accuracy
Peak Detector Accuracy
Test Limits
See test limits in test results Table 22-39 through Table 22-45.
Overview
This test will verify the performance of the Peak detector of the EMI receiver
according to section 5 of the CISPR 16-1-1 :2010 standard. This includes
testing for the following subsections:
5.3 Sine-wave voltage accuracy
5.4 Response to pulses
Table 22-38 Peak Detector - Required Equipment
Item
Critical Specifications
(for this test)
Recommended
Keysight Model
Adapter
a
Type-N (m) to 3.5 mm (f)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.1:1
1250-1744
Adapter
b
3.5 mm (f) to 3.5 mm (f)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.1:1
83059B
Adapter
c
2.4 mm (f) to 3.5 mm (f)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.1:1
11901B
Cable, 1 meter
3.5 mm (m) to 3.5 mm (m)
Frequency: 100 kHz to 1.0 GHz
VSWR: < 1.4:1
11500E
EMI Calibration Pulse Generator CISPR Specified Pulse Area Schwarzbeck IGUU
2916
Power Meter Compatible with power sensor E4418B
Power Sensor Frequency Range: 100 kHz to 100 MHz
Amplitude Range: -60 to 0 dBm
E9304A
a. Quantity 2 required for Option CNF (Type-N RF Input)
b. Only required for Option C35 (3.5 mm RF Input)
c. Only required for Option 544 (44.0 GHz Frequency Range)
