Tests
Test Equipment
Test Equipment
The table below summarizes the test equipment needed to perform all of the
functional tests. Alternate equipment model numbers are given in case the
recommended equipment is not available. If neither the recommended nor the
alternative test equipment are available, substitute equipment that meets or
exceeds the critical specifications listed.
Table 22-1 Required Test Equipment
Item Quantity Critical Specifications
Recommended
Keysight Model
Adapters
Adapter
BNC (f) to SMA (m)
1 Frequency: 40 MHz to 80 MHz 1250-1200
Adapter
Type N (m) to 3.5 mm (m)
1 Frequency: 10 MHz to 18 GHz
VSWR: < 1.1:1
1250-1743
Adapter
Type N (m) to 3.5 mm (f )
1 Frequency: 10 MHz to 1.51 GHz
VSWR: < 1.1:1
1250-1744
Adapter
Type N (m) to BNC (f )
1 Frequency: 10 MHz to 80 MHz
VSWR: < 1.05:1
1250-1476
Adapter
3.5 mm (f) to 3.5mm (f)
1
a
Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.1:1
83059B
Adapter
2.4 mm (f) to 3.5mm (f)
1
b
Frequency: 10 MHz to 50 GHz
VSWR: < 1.1:1
11901B
Adapter
2.4 mm (f) to 3.5mm (m)
1
b
Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.1:1
11901D
Attenuators
Attenuator, 10 dB
3.5 mm (m) to 3.5 mm (f))
2 Frequency:50 MHz
VSWR: < 1.2:1
8493C
Option 010
Attenuator, 10 dB Step
3.5 mm (f) to 3.5 mm (f))
1 Range: 0 to 50 dB
Frequency: 50 MHz
Accuracy: ±0.25 dB
8495A
Option 004
Attenuator, 30 dB
Type-N (m) to Type-N (f)
1 Accuracy: < 0.5 dB @ 50 MHz 11708A
Attenuator, 30 dB
3.5 mm (m) to 3.5 mm (f))
1
c
Accuracy: < 0.5 dB @ 50 MHz 8493C
Option 030
