Keysight N9038A MXE Service Guide 477
Replaceable Parts
Replaceable Parts
Replaceable Parts
Table 17-1 All Replaceable Parts
Reference
Designator
Description Part Number
A1A1 Front Frame Assembly Replacement Kit N9038-60012
A1A1MP1
Front Frame
a
A1A1MP2 Overlay, Main Keyboard N9038-80001
A1A1MP3 Overlay, Input 2 N9038-80002
A1A1MP4 Front Frame Ground Spring W1312-00021
A1A1MP5 Braided gasket 8160-0660
A1A1MP6 Chromeric Gasket 8160-1104
A1A1MP7 Blank Cover Plate N9020-00002
A1A1MP8 Top Trim Strip W1312-40019
A1A1MP9-10 Side Trim Strip W1312-40005
A1A1MP11-12 Side Trim Strip, Vinyl 5041-9172
A1A2 Front Panel Interface Board
(Serial # ≥ MY/SG52260000) W1312-60137
(Serial # < MY/SG52260000) W1312-63092
A1A2MP1 Speaker 9164-0453
A1A2MP2 Speaker Foam N9038-40088
A1A3 Liquid Crystal Display (Serial # ≥ MY/SG52260000) 2090-0997
(Serial # < MY/SG52260000) 2090-0911
A1A4 Display Backlight Power Supply (Serial # ≥ MY/SG52260000) 0950-5235
(Serial # < MY/SG52260000) 0950-4635
A1A5 Front Panel Daughter Board N9038-63005
A1A6 Input 2 LED Board N9038-63006
A1MP1 Main Keypad E4410-40100
A1MP2 Display Keypad E4410-40101
