Keysight N9038A Service Guide

478 Keysight N9038A MXE Service Guide
Replaceable Parts
Replaceable Parts
A1MP3 Nameplate Label, 3.6 GHz (Option 503)
(Option 503 & RT1)
N9038-80027
N9038-80023
Nameplate Label, 8.4 GHz (Option 508)
(Option 508 & RT1)
N9038-80028
N9038-80024
Nameplate Label, 26.5 GHz (Option 526)
(Option 526 & RT1)
N9038-80029
N9038-80025
Nameplate Label, 44.0 GHz (Option 544)
(Option 544 & RT1)
N9038-80030
N9038-80026
A1MP6 Grommet, A1W2 0400-0333
A1MP7 LCD Glass Filter 1000-1513
A1MP8 LCD Lens Gasket W1312-40006
A1MP9 RPG Knob W1312-40017
A1MP10-13 Cable Clamp 1400-1439
A1MP14 Display Bracket (Serial # ≥ MY/SG52260000) W1312-00145
(Serial # < MY/SG52260000) W1312-00115
A1MP15 Shield, Inverter Board W1312-00024
A1MP16 Shield, Inverter Assembly, Top N9020-00010
A1MP17 Shield, Inverter Assembly, Bottom N9020-00011
A1MP19 Shield, Front Panel Interface N9020-00051
A1MP20 Bracket, Input 2 LED Board N9038-21202
A1W1 Flex Circuit,
Front Panel Interface to LCD (Serial # ≥ MY/SG52260000) W1312-60122
(Serial # < MY/SG52260000) W1312-60010
A1W2 Cable Assembly, Wire Harness,
Front Panel Interface
to Backlight Power Supply (Serial # ≥ MY/SG52260000) W1312-60130
(Serial # < MY/SG52260000) W1312-60113
A1W3 Cable Assembly, Wire Harness,
Backlight Power Supply to LCD
W1312-60131
A2 Analog IF Assembly (Serial # ≥ MY/SG53220000) N9020-60011
(Serial # < MY/SG53220000) E4410-60104
Table 17-1 All Replaceable Parts
Reference
Designator
Description Part Number
