Keysight N9038A Service Guide

Keysight N9038A MXE Service Guide 479
Replaceable Parts
Replaceable Parts
A3 Digital IF Assembly (Serial # ≥ MY/SG53220000) N9038-60116
(Serial # < MY/SG53220000) N9020-60119
A3MP1 EMI Gasket, Digital Bus N9038-00004
A3W1 Cable Assembly,
Wire Harness, Smart Noise Source (Serial # ≥ MY/SG53220000) N9020-60090
(Serial # < MY/SG53220000) E4410-60163
A4 CPU Assembly (without A5 disk drive) (PC6/64 Bit/Windows 7) &
(Serial # ≥ MY/SG55260000)
N9038-60212
(PC4/64 Bit/Windows 7) &
(Serial # < MY/SG55260000)
W1312-60196
(PC2/32 Bit/Windows XP) W1312-60102
A4A1 Disk Drive Interconnect Board W1312-63079
A4BT1 Battery, 3V, LI Manganese Dioxide
(CR2032)
1420-0356
A5 Solid State Disk Drive (PC4/64 Bit/Windows 7) N9020-60202
(PC2/32 Bit/Windows XP) N9020-60125
A5MP1 Disk Drive Tray W1312-40078
A5MP2 Disk Drive Rear Panel W1312-00103
A5MP3 Disk Drive Handle 1440-0421
A6 Power Supply Assembly 0950-4934
A7 Midplane Assembly W1312-63095
A8 Motherboard Assembly N9030-63002
A9 RF Attenuator A (0-4 dB) (Option 503, 508, and 526) 33360-60008
RF Attenuator A (0-10 dB) (Option 544) 33326-60013
A10 RF Attenuator B (0-66 dB) (Option 503, 508, and 526) 33321-60083
RF Attenuator B (0-60 dB) (Option 544) 33325-60020
A11 RF Switch/High Band Preamp Assembly (Option 503, 508, and 526) E4410-60170
(Option 544) N9020-60051
A12 YIG Tuned Filter
(YTF)
(Option 503, 508, and 526) 5087-7382
(Option 544) 5087-7383
A12MP1 Gap Pad - YTF Mounting 5022-7179
Table 17-1 All Replaceable Parts
Reference
Designator
Description Part Number
