Keysight N9038A MXE Service Guide 385
Optional Assemblies
A25 Wideband Analog IF Assembly Description
A25 Wideband Analog IF Assembly Connections
The connections to and from the A25 Wideband Analog IF assembly are as
listed in Table 14-1 and as illustrated in Figure 14-1.
While the A25 Wideband Analog IF assembly has a connector (J502) that
connects to the PCI bus on the A8 Motherboard, none of the signals on this
connector are used. The connector is used to give greater stability to the
assembly.
Table 14-1 A25 Wideband Analog IF Assembly Connections
Port Description To/From Cable Frequency
J2 Digital Signal Output A26 Wideband Digital IF J778 W10 Digital
J101 Wideband IF Input A15 Front End Controller J901 W52 300 MHz
J102 Wideband IF Output A3 Digital IF J15 W15 250 MHz
J301 2400 MHz Reference Input A16 Reference J718 W51 2400 MHz
J302 2400 MHz Reference Output n/a n/a 2400 MHz
J502 PCI Bus A8 Motherboard J32 n/a n/a
J801 FPGA Diag n/a n/a n/a
J802 Bias and Control A8 Motherboard J31 n/a n/a
J803 JTAG Programming n/a n/a n/a
J805 Step Cal Input A3 Digital IF J17 W23 n/a
J806 Calibrator Output A16 Reference J726 W50 n/a
