Keysight N9038A Service Guide

Chapter 17 489
Replaceable Parts
Replaceable Parts
Table 17-3 Attaching Hardware
Attach To Qty Part Number Type Type Tool Torque
Analog IF Assembly (A2) Digital IF Assembly (A3) 3 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Attenuators (A9 & A10) Attenuator Brackets
(MP19 & MP20)
2 per 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Attenuator Brackets
(MP19 & MP20)
Chassis Base (MP1) 1 per 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Chassis Sides, Inner
(MP2 & MP4)
1 per 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
AUX IF Cable (W22) Rear Panel (MP6) 1 -- Hex Nut n/a 5/16” Nut
Driver
10 inch-lbs
AUX I/O Cable (W9) Rear Panel (MP6) 2 0380-1858 Hex Head
Standoff
4-40
(.312 in)
3/16” Nut
Driver
9 inch-lbs
Display Backlight Inverter
Board (A1A4)
Display Bracket
(A1MP14)
2 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Display Backlight Inverter
Assembly Top Shield
(A1MP16)
Display Inverter
Assembly Bottom Shield
(A1MP17)
8 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Cal Switch (SW1) SW1 & SW2 Bracket
(MP22)
2 0515-1410 Pan Head M3 X 0.5
(20 mm)
Torx T-10 9 inch-lbs
Chassis Base (MP1) Chassis Sides, Inner
(MP2 & MP4)
12 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
