2MN/2N1
1-3-56
U106 Setting: [Normal2/3]
1. Select the item to be set.
*: 55 ppm model only.
2. Select the paper width to be set.
3. Change the value using the numeric keys.
[1st]
[2nd]
[1st 3/4(Gloss)]
Item No. Description
Display Description
1st Control voltage for the transfer bias for the first side (full speed)
2nd Control voltage for the transfer bias for the second side (full speed)
1st 3/4(Gloss) Control voltage for the transfer bias for the first side at 3/4 times of
line speed
2nd 3/4(Gloss) Control voltage for the transfer bias for the second side at 3/4 times
of line speed
1st B/W* Control voltage for the transfer bias for the first side in black/white
mode
2nd B/W* Control voltage for the transfer bias for the second side in black/white
mode
Display Description
Setting
range
Initial setting
45ppm 55ppm
Width=105 105 mm wide 0 to 255 143 150
Width=210 210 mm wide 0 to 255 134 139
Width=297 297 mm wide 0 to 255 120 128
Display Description
Setting
range
Initial setting
45ppm 55ppm
Width=105 105 mm wide 0 to 255 207 220
Width=210 210 mm wide 0 to 255 155 163
Width=297 297 mm wide 0 to 255 124 128
Display Description
Setting
range
Initial setting
45ppm 55ppm
Width=105 105 mm wide 0 to 255 131 131
Width=210 210 mm wide 0 to 255 123 123
Width=297 297 mm wide 0 to 255 120 120
