Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-3-57
U106 [2nd 3/4(Gloss)]
[1st B/W]
[2nd B/W]
4. Press the OK key. The value is set.
Setting: [Heavy1]
1. Select the item to be set.
2. Select the paper width to be set.
3. Change the value using the numeric keys.l
[1st 3/4]
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
Width=105 105 mm wide 0 to 255 180 180
Width=210 210 mm wide 0 to 255 140 140
Width=297 297 mm wide 0 to 255 120 120
Display Description
Setting
range
Initial setting
55ppm
Width=105 105 mm wide 0 to 255 150
Width=210 210 mm wide 0 to 255 144
Width=297 297 mm wide 0 to 255 128
Display Description
Setting
range
Initial setting
55ppm
Width=105 105 mm wide 0 to 255 183
Width=210 210 mm wide 0 to 255 171
Width=297 297 mm wide 0 to 255 128
Display Description
1st 3/4 Control voltage for the transfer bias for the first side at 3/4 times of
line speed
2nd 3/4 Control voltage for the transfer bias for the second side at 3/4 times
of line speed
Display Description
Setting
range
Initial setting
45ppm 55ppm
Width=105 105 mm wide 0 to 255 133 133
Width=210 210 mm wide 0 to 255 129 129
Width=297 297 mm wide 0 to 255 124 124
