1-2 Service Manual
5026
Note: Some configurations may require a caster base for stability.
Media options
The C746x and C748x printers support the 550-sheet drawer, special media drawers, and 2000-sheet high-
capacity input tray. The C746x and C748x printers support up to four input options. The options can include any
combination of 550 sheet drawers and 550 sheet Specialty Media Drawers, with a maximum of one 2000 sheet
drawer (always at the lowest position.) A caster base is required with some configurations. Including the base
machine capacity of 650 sheets, the C746x and C748x supports up to 4300 sheets.
The Lexmark C74x options are compatible with the Lexmark C73x SFP, X73x MFP, and X74x MFP, but not with
any other Lexmark printers. No other options are supported by the C74x.
The media options include:
• 550-Sheet Drawer—This optional input source installs beneath the printer, and it holds approximately 550
sheets of (20 lb.) paper.
• High Capacity Input Tray—This optional input source installs beneath the printer, and it holds
approximately 2000 sheets of (20 lb.) paper.
• Specialty Media Drawer—This optional input source installs beneath the printer, and it holds
approximately 550 sheets of (20 lb.) paper, or 85 standard envelopes.
Number Description
1 Standard output bin
2 Paper support
3 Printer operator panel
4 Standard 550-sheet stray (Tray 1)
5 Multipurpose feeder
6 Optional 550-sheet specialty media drawer
7 Optional 550-sheet tray
8 Optional 2,000-sheet high.capacity feeder
