Diagnostic information 2-95
5026
3. E-mail the logs to your next level of support.
Note: Some machine SE menus give you the option of clicking Logs Gzip Compressed. If this option is
shown in the menu, then click it and retrieve the compressed log file. Take note of the destination folder
where the log file is saved.
C. Collecting the settings from the menu settings page
Note: The menu settings page is different for each printer. For more information see the User’s Guide. Your
next level of support will tell you which page they want to see.
Copying the menu settings page from the Embedded Web Server (EWS)
Note: Make sure your printer is connected to a network or to a print server.
1. From a Web browser, type http://printer_IP_address, and then press Enter.
2. Click Settings, and then select one of the settings page from the links shown on the page.
3. Copy all information, and then save it as a text file.
4. E-mail the text file to your next level of support.
Printing the menu settings page
1. From the home screen, navigate to Reports > Menu Settings Page.
2. Print the menu settings page, and then use Scan to E-mail to send it to your next level of support.
D. Collecting information from the user
Ask the user for information about the following:
• Print job being run
• Operating system used
• Print driver used
• Other information on what was happening when the 9yy error occurred.
900.00–900.99 (except 900.05)—System software error service check
Note: Make sure to perform the “Steps before starting the 9yy service checks” on page 2-94 first before
proceeding.
There are different types of 900.xx errors that can occur. There may be a communication problem (Bad cable,
network connection, and so on) software issue, or a hardware problem with the controller board, or ISP (Internal
solutions port). The communication and software aspects should be checked first. Determine if the problem is
constant or intermittent. Use the troubleshooting procedure below to isolate the issue. Take any notes as
instructed. You will need that information in the event you need to contact your next level support.
Note: Before troubleshooting, determine the operating system used when the error occurred. If possible
determine whether a PostScript or PCL file was sent to the device when the error occurred. Ask the customer
which Lexmark Solutions applications are installed on the device.
Step Action and questions Yes No
1 POR the device.
Does the error reoccur?
Go to step 2. Problem
resolved.
