Lexmark CS748de - Rear Right Cover Removal

Repair information 4-49
5026
Go Back
Previous
Next
Rear right cover removal
See “Rear right cover” on page 7-3 for the part number.
1. Remove the right cover. See “Right cover removal” on page 4-51.
2. Press the two tabs (A) to separate the right cover from the rear right cover.
A
