7-14 Service Manual
5026
Go Back
Previous
Next
Assembly 7: Top
Index P/N
Units/
mach
Units/
FRU
Description
7—1 40X5122 1 1 Color-On-Demand assembly
2 40X5109 1 1 Cooling fan
3 40X5130 1 1 Top cover camshaft assembly
4 40X5108 1 1 Cartridge cooling fan
3
4
1
2
