Parts catalog 7-13
5026
Go Back
Previous
Next
Assembly 6: Left
Index P/N
Units/
mach
Units/
FRU
Description
6—1 40X5137 1 1 Contact springs kit
Includes the following:
• A—Torsion PCD contact spring
• B—Torsion CR contact spring
• C—Contact spring cap
• D—Charge roll contact spring
• E—HVPS TAR contact spring
• F—HVPS doctor/developer contact spring
• G—HVPS Db contact spring
• Screw
2 40X7159 1 1 Auger shaft and gear parts pack
3 40X5307 1 1 Waste toner HV contact assembly
4 40X5129 1 1 High-voltage power supply
5 40X1416 4 1 Toner level sensor
6 40X8373 1 1 Toner cartridge contacts
