Parts catalog 7-17
5026
Go Back
Previous
Next
Assembly 10: Optional special media tray assembly
Index P/N
Units/
opt.
Units/
FRU
Description
10—1 40X5142 1 1 Special media assembly, including tray
2 40X5152 2 2 Pick arm roll, 550-sheet drawer
3 40X5143 1 1 Special media tray assembly
1
3
2
