Diagnostic aids 3-63

5026

Go Back

Electrophotographic (EP) process

Main components

System board

The system board is the brain of the printer. During the print process, an image is sent from a computer to the

system board. The raster image processor (RIP) portion of the system card converts the data into a raster image

and feeds this data along with control information to the printhead.

Fuser

Printhead

High voltage

power supply

Developer (toner)

cartridge

Transfer belt

Photoconductor

belt

System

board
