General information 1-5
5026
Clearances
Memory
Number Description Clearance
1 Right side 101.6 mm (4 in.)
2 Front 609.6 mm (24 in.)
3 Left side 152.4 mm (6 in.)
4 Rear 152.4 mm (6 in.)
5 Top 304.8 mm (12 in.)
C746 C748
Standard memory—The standard RAM is soldered onto the system board.
Memory size
512MB 512MB
Optional memory—Optional DIMM (Dual Inline Memory Module) is a card that can be plugged into an
available memory slot on the system board. Flash memory is a card that can also be plugged into an
available slot.
Maximum number of memory (DIMM) slots
11
Maximum number of flash memory slots
11
DIMM memory sizes available
256MB, 512MB, 1024MB 256MB, 512MB, 1024MB
Flash (Nand Flash)
256 256
Maximum possible memory
1536MB 1536MB
