Parts catalog 7-1
5026
Go Back
Previous
Next
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
• Asm-index: Identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and item number 1 in the table.
• Part number: Identifies the unique number that identifies this FRU.
• Units/mach: Refers to the number of units actually used in the base machine or product.
• Units/option: Refers to the number of units in a particular option. It does not include the rest of the base
machine.
• Units/FRU: Refers to the number of units packaged together and identified by the part number.
• NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
• Model information used in the parts catalog:
Asm-
index
Part
number
Units/mach
Units/
FRU
Description
Abbreviation
used
Machine type
and model
Printer name Description
310 5026-310 Lexmark C746n Network-ready
330 5026-330 Lexmark C746dn Network-ready with duplex
330 5026-330 Lexmark C746dtn Network-ready with duplex and 550 sheet
tray
510 5026-510 Lexmark C748e Network-ready with etask touch screen
530 5026-530 Lexmark C748de Network-ready with etask touch screen and
duplex
530 5026-530 Lexmark C748dte Network-ready with etask touch screen,
duplex, and 550 sheet tray
539 5026-539 Lexmark CS748de Network-ready with etask touch screen and
duplex
311 5026-311 Lexmark C746n Network-ready
331 5026-331 Lexmark C746dn Network-ready with duplex
331 5026-331 Lexmark C746dtn Network-ready with duplex and 550 sheet
tray
511 5026-511 Lexmark C748e Network-ready with etask touch screen
531 5026-531 Lexmark C748de Network-ready with etask touch screen and
duplex
531 5026-531 Lexmark C748dte Network-ready with etask touch screen,
duplex, and 550 sheet tray
538 5026-538 Lexmark CS748de Network-ready with etask touch screen and
duplex
