1-4 Service Manual
5026
Go Back
Previous
Next
Printer specifications
Dimensions
The following table contains the dimensions and weight for each of the respective printer models. This does not
include packaging.
Height Width Depth Weight
Basic printer (C746n/dn) 454.7 mm
(17.9 in)
435.0 mm
(17.1 in)
400.0 mm
(15.7 in)
25.2 kg
(55.6 lbs)
Basic printer (C748e/de) 454.7 mm
(17.9 in)
435.0 mm
(17.1 in)
400.0 mm
(15.7 in)
25.6 kg
(56.4 lbs)
C746dtn printer, with 550-sheet
optional drawer
581.7 mm
(22.9 in)
435.0 mm
(17.1 in)
545.0 mm
(21.5 in)
29.7 kg
(65.5 lbs)
C748dte printer, with 550-sheet
optional drawer
581.7mm
(22.9 in)
435.0 mm
(17.1 in)
545.0 mm
(21.5 in)
30.1kg
(66.4 lbs)
550-sheet drawer 169.0 mm
(6.6 in)
435.0 mm
(17.1 in)
545.0 mm
(21.5 in)
4.5 kg
(10.0 lbs)
550-sheet special media drawer 169.0 mm
(6.6 in)
435.0 mm
(17.1 in)
545.0 mm
(21.5 in)
4.5 kg
(10.0 lbs)
2000-sheet high capacity feeder 387.0 mm
(15.2 in)
435.0 mm
(17.1 in)
545.0 mm
(21.5 in)
26.1 kg
(57.5 lbs)
Spacer 169.0 mm
(6.6 in)
435 mm
(17.1 in)
545 mm
(21.5 in)
3.2 kg
(7.0 lbs)
Caster Base 127.0 mm
(5.0 in)
778 mm
(30.6 in)
812.0 mm
(32.0 in)
43.1 kg
(95.0 lbs)
