Parts catalog 7-3
5026
Assembly 1: Covers (C746)
Index P/N
Units/
mach
Units/
FRU
Description
1—1 40X7520 1 1 Top access cover assembly, 2.3 inch
2 40X7660 1 1 2.3 inch operator panel buttons parts package
Includes the following:
• Button kit
• Sleep button
• Return button
• Select button
• Navigation button
• Home button
• LED Lens
3 40X5121 1 1 Bin full sensor with cable
4 40X7603 1 1 2.3 inch operator panel assembly with card
Includes the following:
• LCD Display
• UICC card
5 40X7966 1 1 Top access cover parts package
Includes the following:
• Bin full flag
• Operator panel display bracket
6 40X5106 1 1 Output bin extension cover
7 40X5103 1 1 Rear upper cover
8 40X5993 1 1 Top cover assembly
9 40X5287 1 1 Cooling fan filter
10 40X5145 1 1 Rear frame cover
11 40X5105 1 1 Rear right cover
12 40X5153 1 1 Dust cover assembly
13 40X5104 1 1 Rear left cover
14 40X5994 1 1 Right cover
15 40X7661 1 1 Front access door cover assembly
16 40X5102 1 1 Left cover
17 40X5119 1 1 Top access cover links (slider cam)
Note: The left link is also available in the top access cover assembly and
the right link is also available in the EP drive assembly
18 40X8317 1 1 Operator panel bezel, C74x (blank logo)
18 40X6879 1 1 Operator panel bezel, C746n
18 40X7335 1 1 Operator panel bezel, C746dn and C746dtn
