Parts catalog 7-5
5026
Assembly 2: Covers (C748)
Index P/N
Units/
mach
Units/
FRU
Description
2—1 40X5988 1 1 Top access cover assembly, 4.3 inch
2 40X5990 1 1 4.3 inch operator panel buttons parts package
Includes the following:
• Button kit
• Home button
• Sleep button
• LED Lens
3 40X5121 1 1 Bin full sensor with cable
4 40X5989 1 1 UICC card
5 40X7116 1 1 4.3 inch LCD display
6 40X7966 1 1 Top access cover parts package
Includes the following
• Bin full flag
• Operator panel display bracket
7 40X5106 1 1 Output bin extension cover
8 40X5103 1 1 Rear upper cover
9 40X5993 1 1 Top cover assembly
10 40X7703 1 1 Speaker
11 40X5287 1 1 Cooling fan filter
12 40X5145 1 1 Rear frame cover
13 40X5153 1 1 Dust cover assembly
14 40X5105 1 1 Rear right cover
15 40X5994 1 1 Right cover
16 40X7661 1 1 Front access door cover assembly
17 40X5104 1 1 Rear left cover
18 40X5119 1 1 Top access cover links (slider cam)
Note: The left link is also available in the top access cover assembly and
the right link is also available in the EP drive assembly
19 40X5102 1 1 Left cover
20 40X8317 1 1 Operator panel bezel, C74x (blank logo)
20 40X6877 1 1 Operator panel bezel, C748de
20 40X8259 1 1 Operator panel bezel, C748e
