Parts catalog 7-19
5026
Assembly 11: Optional high-capacity input option (HCIT)
Index P/N
Units/
option
Units/
FRU
Description
11—1 40X5157 1 1 Top plate assembly
2 40X5168 2 2 HCIT pick arm roll
3 40X5156 1 1 Feed with bushing
4 40X5149 1 1 HCIT rear cover
5 40X4585 2 1 Tray latch with spring
6 40X5159 1 1 HCIT controller card assembly
7 40X4587 1 1 Slide assembly with springs
8 40X5147 1 1 HCIT right cover
9 40X5155 1 1 Elevator motor with sensor
10 40X5158 1 1 Photointerrupter sensor with cable assembly
11 40X4593 2 1 HCIT drawer slide assembly
12 40X5146 1 1 HCIT front tray cover
13 40X5144 1 1 HCIT paper drawer tray assembly
14 40X5148 1 1 HCIT left cover
