2-56 Service Manual
5026
Go Back
Previous
Next
4
1. Connect a new MPF motor with cable to
the JDX1 connector on the system board
from outside of the machine.
2. Bring the printer up in Diagnostics Menu
(Turn off the printer, press and hold
buttons 3 and 6, then turn on the printer).
3. Navigate to MOTOR TESTS > Duplex >
Forward or Reverse.
Note: Perform this test for 5 to 10
seconds only.
4. Navigate to MOTOR TESTS > MPF Test>
Forward or Reverse.
Note: Perform this test for 5 to 10
seconds only.
5. Check if the motor would turn for each
test.
Does this clear the problem?
Go to step 5. Replace the system board.
See “System board
removal” on page 4-163.
5
1. Disconnect the MPF motor cable on the
motor side.
2. Connect a new motor from outside of the
machine.
3. Bring the printer up in Diagnostics Menu
(Turn off the printer, press and hold
buttons 3 and 6, then turn on the printer).
4. Navigate to MOTOR TESTS > Duplex >
Forward or Reverse.
Note: Perform this test for 5 to 10
seconds only.
5. Navigate to MOTOR TESTS > MPF Test>
Forward or Reverse.
Note: Perform this test for 5 to 10
seconds only.
6. Check if the motor would turn for each
test.
Does the error still exist?
Go to step 6. Replace the MPF duplex
motor assembly. See
“Multipurpose feeder
(MPF)/duplex motor
assembly removal” on
page 4-133.
6
Connect a new MPF motor cable to the old
MPF motor and connect it to JDX1 connector
on the system board.
Does the error still exist?
Go to step 7. Replace the MPF/duplex
motor cable. See
“Multipurpose feeder
(MPF)/duplex motor
cable removal” on
page 4-136.
7
1. Open the front door cover.
2. Check the duplex reference edge guide
assembly for any damage.
3. Check rollers and belts for damage and
misalignment.
4. Bring the printer up in Diagnostics Menu
(Turn off the printer, press and hold
buttons 3 and 6, then turn on the printer).
5. Remove the input tray.
6. Navigate to MOTOR TESTS > Duplex >
Forward.
7. Check if the duplex assembly runs.
8. Check if the MPF/duplex gear turns.
Is the duplex reference edge guide assembly
free of damage?
Replace the duplex
reference edge guide
assembly. See “Duplex
reference edge guide
assembly removal” on
page 4-95.
Go to step 8.
Step Questions / actions Yes No
