4-12 Service Manual

7562

Go Back

6. Open the multipurpose feeder.

7. Slide the paper guide all the way to the left. Carefully use a flat-blade screwdriver to lift the multipurpose

feeder inner cover, and remove.

Note: Be careful not to scratch or mar the cover.

Note: Using a flat-blade screwdriver, pry out the back pin (D) far enough to be able to grasp the ends.

D (10J2832)
