IPECS Release 5
Feature Description & Operation 5.0
2-128
NO SMDR record number, optional output, (PGM 177-Btn 23)
STA 3 or 4 digit station number.
CO 2 or 3 digit CO Line number
Time Call duration in minutes and seconds
Start Date and time call was placed/received
NUM I Flex Field I, for outgoing call displays dialed number, for incoming call displays
Ring duration, CLI or CPN (PGM 177-Btn 20
Cost Cost of Call
Account Code Account code entered for call
NUM II Flex Field II for incoming call, displays Ring duration, CLI or CPN or blank,
(PGM 177-Btn 23)
DC Disconnect Cause, optional output (PGM 177-Btn 29), with value:
01~7F: Follow cause value of Q.931 specification,
81: Disconnected, toll restricted
84/85: Disconnected, disconnect supervision
0: Other
The SMDR record output for internal calls is as shown in the figure below.
---- Site Name : ---------------------------------------------------------------------
STA CO TIME START DIALED NUMBER COST ACCOUNT CODE CPN NUMBER
----- --- -------- -------------- --------------------- ---------- ----------- --------------------
102 00:00:01 06/11/08 10:53 E103
102 00:00:00 06/11/08 14:13 S103
102 00:00:10 06/11/08 11:05 E Conf Rm 1
120 00:00:03 06/11/08 11:11 P123
STA DIALED Meaning
100 E101
1) Station 100 called station 101 and station 101 answered.
2) In a conference, station 100 was a conference master, station 101 was a
conference member.
105 S103 Station 105 sent an internal SMS to station 103
110 E Conf Rm 1 Station 110 was the member of conference room 1.
120 P123 Station 120 paged station 123
Operation
System
For real-time SMDR, records are output after completion of the call as shown in the figure above
System Attendant
To print SMDR records
1. Press the [
PGM] button.
2. Dial ‘0111’, the SMDR print code.
3. Enter the desired station range.
4. Press the [
SAVE] button.
To Next Page
