IPECS Release 5
Feature Description & Operation 5.0
2-156
2.70.4 Traffic Analysis, CO/IP Reports
Description
The CO/IP Traffic Summary and Hourly reports provide statistics on a summary or hourly basis for
CO/IP Group activity. The following provides a sample report and description of the major fields in
the report.
Site Name : abc co
Report Type : CO Group Summary Report- Today Peak
Date : 09/08/02 08:34
===========================================================================================
Peak Hour for All CO 11:00
Grp Num Anal Total Total Inc Out Grp % %
No COs Hour Usage Seize Seize Seize Ovl ACB FAO
1 16 10:00 9 6 4 2 0 0 0
20 1 10:00 1 1 0 1 0 0 0
Field Description
Grp No. CO/IP Group number
Anal Hour (Analysis hour) hour during the analysis period with peak usage.
Total Usage Total number of call attempts on CO/IP lines in the Group
Total Seize Total number of times CO/IP lines in the group were used for any call
Inc Seize (Incoming Seizures) Total number of incoming calls answered for CO/IP lines in the
group.
Out Seize (Outgoing Seizures) Total number of outgoing calls attempted on CO/IP lines in the
group.
ACB (All COs Busy) Percentage of the time that all CO/IP lines in the group were
simultaneously busy.
FAO (Failed Attempts Outgoing) Percentage of outgoing calls offered to the CO/IP lines in
the group that were denied due to All Trunks Busy condition.
Operation
System Attendant
To print the CO/IP Traffic Summary Report
1. Press the [
PGM] button.
2. Dial ‘0128’, the CO/IP Traffic Summary report code.
3. Select Analysis Period (‘1’-‘5’).
4. Press the [
SAVE] button.
To print the CO/IP Hourly Traffic Report
1. Press the [
PGM] button.
2. Dial ‘0128’, the CO/IP Hourly Traffic report code.
3. Select Analysis Period (‘1’-‘5’).
4. Press the [
SAVE] button.
Conditions
Programming
SYSTEM 1. RS-232 Port Settings (PGM 174)
2. Serial Port Function Selections (PGM 175)
