Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Misc. (Env.) Discrete Teleme-
try 1 per Shelf
178 150 ft. 807AS J67 (at CO)
J68 (at RT)
194 50
179 (D.A.) As Reqd.
Table 2-4 Notes:
1. Discontinued Availability means cable can no longer ordered.
2. All cables are 26 gauge.
3. TBOS is not available in OC-12, Release 7.
4. Parallel telemetry is not available in OC-12, Release 7.
Table 2-5 ED-8C724-22 Telemetry and LAN Cable Assemblies
Description ED-8C724-22 Group
Cable Length
(ft.)
(Notes 1 & 2)
Cable
Type
DDM-2000
Backplane
Connections
TL1/X.25 Interface -
1 per shelf
15 50 811AS J61
16 75
17 100.
18 125
28 125
70 250
ED-8C727-20 G165 150
ED-8C727-20 G186 300
ED-8C727-20 G166 (D.A.) As Req’d.
IOA LAN
One per shelf
41 150 J74
41A 30
41B 75
42 300.
Table 2-4 Telemetry and Modem Cable Assemblies (Continued)
Description
ED-8C727-20 Group
(Note 1)
Cable
Length (ft.)
(Note 2)
Cable
Type
DDM-2000
Backplane
Connections
