Lucent Technologies DDM-2000 OC-12 - Table 3-6 Front Access Mult Cable Assemblies

 Issue 5 November 2000
363-206-208
Equipment and Front Access Cable Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 3-6 Front Access Mult Cable Assemblies
Description
ED-8C727-21
Group
Cable
Length (ft.)
(Note)
Cable Connector
(to OC-12
Backplane)
Other End
Connector (To
Mating Cable)
DS1 Timing Mult. 212 4’ 4" P65 P266
213 (D.A.)
2
As Reqd.
Sync Input Timing ED-8C724-20
Group 394
3 P266 * J266/J237
Parallel Telemetry** Mult. 220 4’ 1" P22 J221
221 (D.A.)
2
As Reqd.
Office Alarms Mult. 224 4 P64 J263
225 (D.A.)
2
As Reqd.
TBOS‡ Mult. 226 2’ 8" P72 J273/J258A
227 (D.A.)
2
As Reqd.
TBOS‡
Mult.
228 3’ 10" P73 P273/P258A
229 (D.A.)
2
As Reqd.
Mult w/o TBOS‡ ED-8C724-20
Group 427
5" P258A† J258A
Table 3-6 Notes:
* The ED-8C724-20, Group 394 sync input timing cable is required ONLY if the DDM-2000 OC-12 shelf is
equipped with BBF2B/BBF4 circuit packs configured for providing a sync output for the BITS clock. The
BBF2B/BBF4 circuit packs are externally timed to a DS1 reference. The Group 394 cable connects to
J266 of the Group 210 cable on the DDM-2000 OC-12 shelf in series with the cable that is providing the
incoming external reference signal.
† This cable does not connect to the backplane. It is used between the TBOS mult cables, when CIT and
modem are to be multed without TBOS.
‡ TBOS is not available in OC-12, Release 7.
** Parallel telemetry is not available in OC-12, Release 7.
1. Cable lengths listed as required are specified by the customer.
2. Discontinued Availability (D.A.) means cable can no longer ordered.
