Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Introduction
Lucent Technologies - Proprietary
See Notice on first page
Equipment
Miscellaneous Equipment
Miscellaneous equipment is listed in Table 1-1 on page 1-4.
NOTE:
Not all equipment is required for each installation.
Test Equipment
Tools, test sets and accessories are listed in Table 1-2.
NOTE:
Not all tools are required for each installation.
Table 1-1 Miscellaneous Equipment
Item Equipment Code or Commercial Code Comcode
Network Bay Frame
(Front or Rear Access - 7 ft.)
ED-8C500-50, G1
Network Bay Frame
(Rear Access Only - 7 ft.)
ED-8C501-50, G1
Seismic Network Bay Frame
(Front or Rear Access - 7 ft.)
ED-8C800-50, G1
Seismic Network Bay Frame
(Front Access Only - 7 ft.)
ED-8C801-50, G1
Stile Cover Assemblies
*
846108843
Stile Cover Brackets* 846170017
DDM-2000 OC-12 Shelf Assembly ED-8C727-30, G1 or G4
Heat Baffle Assembly ED-8C733-30, G1
Fan Shelf Assembly
†
ED-8C733-30, G8
DDM-2000 OC-12 Cable Assemblies ED-8C727-20, -21
Bracket 4.82" for ED-8C500 or 8C800 Frame 846592913
Bracket 5.94" for ED-8C500 or 8C800 Frame 846593002
Bracket 2.00" for ED-8C501 or 8C801 Frame 846600229
Bracket 3.82" for ED-8C501 or 8C801 Frame 846592905
