Lucent Technologies DDM-2000 OC-12 Installation Manual

Issue 5 November 2000 
363-206-208
Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 2-6 DS1 Timing Cable Assemblies
Description ED-8C727-20 Group
Cable
Length(ft.)
Cable
Type
DDM-2000 Backplane
Connections
DS1 Timing Reference
Input
151 100 BF† J66/J65
152 300
182 150
183 450
153 (D.A.)* As Reqd.
DS1 Timing MULT
for Additional OC-12
Shelves
154 5 745AS‡ J66 toJ65
(Lower Shelf)
155 (D.A.)* As Reqd. BF† J66 toJ65
(None adjacent)
184 50
DS1 Timing MULT
for Additional OC-3 Shelf
ED-8C724-20 G380 4 BF† P65 (OC-12 Shelf) to
P37 (OC-3 Shelf Pos.
1)
Sync Input Timing
(Prevents Timing Loop)
ED-8C724-20
G394‡
3 BF† J65 to P237(OC-12
Shelf), J237 to
Incoming external
reference cable
DS1 Timing Termination
Plug
ED-8C724-20 G397 J65
DS1 Timing from FT-2000 ED-8C724-22 G29 75 BF† J66 to FT-2000
ED-8C724-22 G71 50
ED-8C724-22 G72 150
ED-8C724-22 G30
(D.A.)*
655
Table 2-6 Notes:
* Discontinued Availability means cable can no longer ordered.
† The BF type cable is 22 gauge.
‡ 745AS cable is 26 gauge
** The ED-8C724-20 Group 394 sync input cable is required ONLY if the DDM-2000 OC-12 shelf is
equipped with BBF2B/BBF4 circuit packs configured for providing a sync output for the BITS clock and
the BBF2B/BBF4 circuit packs are externally timed to a DS1 reference. The Group 394 cable connects
to P66 on the DDM-2000 OC-12 shelf in series with the cable that is providing the incoming external ref-
erence signal.
