Issue 5 November 2000 
363-206-208
Lucent Technologies - Proprietary
See Notice on first page
5
Powering, Verification, and Circuit Pack
Installation for the DDM-2000 OC-12
Multiplexer
Overview
This section provides information for verifying that the shelf is being supplied with the
proper power and provides instructions for circuit pack option settings and installation.
Detailed information on the function of each circuit pack is contained in 363-206-290
(Release 5), 363-206-295 (Release 7) or 363-206-207 (Releases prior to 5)
DDM-2000
OC-12 Multiplexer User/Service Manual.
Software Download
The software download procedure in this section is required for all DDM-2000 OC-12
shelves, as the BBG8 SYSCTL and BCP4 OHCTL (Release 5 and 7) or BBG5
SYSCTL and BCP1 OHCTL (Releases prior to 5) circuit packs are shipped from the
factory without the software installed. A software package containing the necessary
computer diskettes and a software release description document should be provided
with the circuit packs.
NOTE:
Types of circuit packs available and quantities per shelf as shown in Table 5-1 on
page 5-14.
Software download requires an MS-DOS
*
compatible personal computer (PC) and an
EIA-232 interface cable for connecting the PC to the connector on the faceplate of the
shelf’s user panel.
* Registered trademark of Microsoft Corporation.
