To reduce the possibility of ESD damage, assemblies are equipped with grounding
jacks to enable personnel to ground themselves using wrist straps (see Figure 1) while
handling circuit packs or working on an assembly. The jacks for connection of wrist
straps are located at the lower right-hand corner of each assembly and are labeled.
When grounding jacks are not provided, an alligator clip adapter enables connection to
bay frame ground.
Figure 1. Static Control Wrist Strap
Ground
To
Connection
