 Issue 5 November 2000

363-206-208

Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer

Lucent Technologies - Proprietary

See Notice on first page

Note: There are two brackets required per shelf to hold the cable channel in place.

Figure 2-5. DDM-2000 OC-12 Shelf Mounting (Top View)
