Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Powering, Verification, and Circuit Pack Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 5-1 Notes:
1. Maximum per shelf is based on Point-to-point applications only.
2. Minimum functionality, as defined here, includes protection switching, thus protection circuit packs are
included.
* The BBG8 SYSCTL and BCP4 OHCTL are used with Release 5 or 7.
† The function unit slot positions may be equipped with BBG11 3DS3s, BBG12 3STS1Es, 21G3-U OLIUs, or
21D-U OLIUs, or some other combination of pairs of these circuit packs, (Release 3.0 Ring software will
not accept OLIUs in function unit positions).
†† The 23H-U OLIU is a 1550nm long reach regenerator.
§ Unequipped function unit shelf position slots MUST be filled with 177B apparatus blanks to ensure proper
air flow.
§§ Unequipped MAIN shelf position slots MUST be filled with 177C apparatus blanks to ensure proper air
flow.
Table 5-1 DDM-2000 OC-12 Circuit Pack Codes
Product Code Description
Max/ Shelf
(Note 1)
Min/ Shelf
(Note 2)
ED-8C727-30, G1 DDM-2000 Shelf Assembly - -
BBG5 or BBG8 * SYSCTL Circuit Pack 1 1
BCP1 or BBG4 * OHCTL Circuit Pack 1 1
BCP3 TSI Circuit Pack 2 2
BBF2B or BBF4 TGS Circuit Pack 2 2
BBG11/BBG11B 3DS3 Circuit Pack
8
†
2
†
BBG12 3STS1E Circuit Pack
21G3-U OLIU Regenerator
21D-U OLIU Regenerator
23G-U or 23H-U
††
OLIU Regenerator 2 2
177B
§
Apparatus Blank (8") 6 0
177C
§§
Apparatus Blank (12") 2 2
