Lucent Technologies DDM-2000 OC-12 Installation Manual

Issue 5 November 2000 
363-206-208
Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 2-17 Color-Code Cross-Reference
Number
Color Paired With
Old New Old New
1C or 26C
2C or 27C
3C or 28C
4C or 29C
5C or 30C
BL1W
O1W
G1W
BR1W
S1W
W-BL
W-O
W-G
W-BR
W-S
BL2W
O2W
G2W
BR2W
S2W
BL-W
O-W
G-W
BR-W
S-W
6C or 31C
7C or 32C
8C or 33C
9C or 34C
10C or 35C
BL1R
O1R
G1R
BR1R
S1R
R-BL
R-O
R-G
R-BR
R-S
BL2R
O2R
G2R
BR2R
S2R
BL-R
O-R
G-R
BR-R
S-R
11C or 36C
12C or 37C
13C or 38C
14C or 39C
15C or 40C
BL1BK
O1BK
G1BK
BR1BK
S1BK
BK-BL
BK-O
BK-G
BK-BR
BK-S
BL2BK
O2BK
G2BK
BR2BK
S2BK
BL-BK
O-BK
G-BK
BR-BK
S-BK
16C or 41C
17C or 42C
18C or 43C
19C or 44C
20C or 45C
BL1Y
O1Y
G1Y
BR1Y
S1Y
Y-BL
Y-O
Y-G
Y-BR
Y-S
BL2Y
O2Y
G2Y
BR2Y
S2Y
BL-Y
O-Y
G-Y
BR-Y
S-Y
21C or 46C
22C or 47C
23C or 48C
24C or 49C
25C or 50C
BL1V
O1V
G1V
BR1V
S1V
V-BL
V-O
V-G
V-BR
V-S
BL2V
O2V
G2V
BR2V
S2V
BL-V
O-V
G-V
BR-V
S-V
Table 2-17 Notes:
1. Some cables may be manufactured using wires following old color code stan-
dards. This tables provides a color code cross-reference.
