Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Inspection
Description
Perform the following procedure before the DDM-2000 OC-12 Multiplexer installation or
cable installation.
Procedure
(1) Verify that the frame or structure into which the DDM-2000 OC-12 Multiplexer
will be installed is properly grounded.
NOTE:
Each DDM-2000 OC-12 shelf, heat baffle, and fan shelf comes equipped with a
pouch, attached to the shelf (or baffle), containing the hardware required for
mounting and grounding and an installation kit.
The installation kit for the baffle contains:
The installation kit for the shelf contains:
NOTE:
Each DDM-2000 OC-12 shelf also comes equipped with a copy of 363-206-207,
DDM-2000 OC-12 Multiplexer User/Service Manual .
The installation kit for the fan shelf contains:
Quantity Description
4 0.216-24 x 5/16” Thread Cutting Screws (C803535012)
Quantity Description
4 0.216-24 x 5/16” Screws (C803535012)
2 Fuses
Quantity Description
4 0.216-24 x 5/16” Screws (C803535012)
6 Cable Ties
1 Taptite Screw
1 Grounding Cable
