Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Equipment and Front Access Cable Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 3-4 Front Access DS3 Cable Assemblies
Description
ED-8C727-21
Group
Cable
Length (ft.)
Cable Connector
(to Backplane)
Other End
Connector
Cable From OC-12
Backplane To Front
of Shelf
MULDEM A
201 3’ 4" P30 J30-1A
P31 J31-2A
P32 J32-3A
P33 J33-1A
P34 J34-2A
P35 J35-3A
Cable From OC-12
Backplane To Front
of Shelf
MULDEM B
202 3.5 P36 J36-1B
P37 J37-2B
P38 J38-3B
P39 J39-1B
P40 J40-2B
P41 J41-3B
Cable From OC-12
Backplane To Front
of Shelf
MULDEM C
203 2’ 11" P42 J42-1C
P43 J43-2C
P44 J44-3C
P45 J45-1C
P46 J46-2C
P47 J47-3C
Cable From OC-12
Backplane To Front
of Shelf
MULDEM D
204 2’ 9" P48 J48-1D
P49 J49-2D
P50 J50-3D
P51 J51-1D
P52 J52-2D
P53 J53-3D
