Issue 5 November 2000
363-206-208
Equipment and Front Access Cable Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Note: The cabling stacking order is shown in the figure. The numbers on the cables indicate the shelf associ-
ated with that cable.
Figure 3-2. ED-8C500 Frame, Front Access Cable Placement
