Equipment and Front Access Cable Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Parallel telemetry cable options are listed in Table 3-5 on page 3-37.
Parallel telemetry connections are listed in Table 3-9 on page 3-40.
Telemetry Equipment Connections
NOTE:
Perform this procedure for shelf 1, which will be directly connected to the teleme-
try system.
(1) Obtain a Group 232 or 213 parallel telemetry cable listed in Table 3-7 on page
3-39.
(2) Connect the cable to P221 of the Group 218 or 219 front access cable, which is
already connected to shelf 1.
(3) Route the parallel telemetry cable out of the DDM-2000 OC-12 bay to the telem-
etry system, stacking the cable as shown in Figure 3-2 on page 3-47.
(4) Cut the parallel telemetry cable to the desired length at the telemetry panel.
(5) Wire-wrap the loose end of the parallel telemetry cable to the telemetry system
making connections as shown in Table 3-9 on page 3-40.
(6) Dress and secure the cable in the bay.
