Lucent Technologies DDM-2000 OC-12 Installation Manual

Issue 5 November 2000 
363-206-208
Lucent Technologies - Proprietary
See Notice on first page
4
DDM-2000 OC-3/OC-12 Bay
Installation
Overview
This section provides installation information for the ED8C906-30 OC-3/OC-12
Bay.
Description
This section should be performed when DDM-2000 OC-3 and OC-12 shelves are
factory furnished in the ED8C906-30 OC-3/OC-12 Bay. The ED8C906-30 OC-3/
OC-12 bay provides six configurations of OC-3 and OC-12 shelves and
associated fan shelves, heat baffles. An optional fuse panel may also be
furnished. See table below for ED8C906-30 Bay configurations.
Figure 4-1 on page 4-11 shows the bay layout for the Group 4 and Group 6 bay
configurations. Typically the DDM-2000 OC-3 & OC-12 bay frame type is a 7-foot
network
*
bay framework. The 7-foot seismic network
†
bay framework is also
available.
ED-8C906-30 DDM-2000 Shelves Equipped Fuse Panel
Group 1 (6) OC-3 Shelves No
Group 2 (6) OC-3 Shelves Yes
Group 3 (4) OC-3 Shelves, (1) OC12 Shelf No
Group 4 (4) OC-3 Shelves, (1) OC12 Shelf Yes
Group 5 (3) OC-12 Shelves No
Group 6 (3) OC-12 Shelves Yes
* ED-8C500-50 or ED8C501-50
† ED8C600-50 or ED8C801-50
