Lucent Technologies DDM-2000 OC-12 - Bay Anchoring; Tools, Test Sets, and Accessories

Issue 5 November 2000 
363-206-208
DDM-2000 OC-3/OC-12 Bay Installation
Lucent Technologies - Proprietary
See Notice on first page
Bay Anchoring
Network bay frames are approved for Seismic Zones 0, 1, 2 only, while Seismic bay
frames are approved for all Seismic Zones. The bay anchor type and quantity required
for bay installation are shown below:
Tools, Test Sets, and Accessories
The following tools or equivalent are required:
Qty Description
4 402980056 Hilti Fastening Systems #590024.500
*
* Drop-In Anchors for floor supported only Network type frames
in Seimic Zone 0, 1,2.
4 406899229 Hilti Fastening Systems #00217742
†
† Heavy Duty Anchors for floor supported only 600 type frames
in all Seimic Zones.
2 402980056 Hilti Fastening Systems #590024.500
‡
‡ Drop-In Anchors for top and floor supported Network type
frames in Seimic Zone 0, 1,2.
2 406899229 Hilti Fastening Systems #00217742
**
** Heavy Duty Anchors for top and floor supported Seimic type
frames in all Seimic Zones.
Quantity Description
1 Vacuum Cleaner
*
* Required for cleaning area after floor drilling.
1 Drill Hammer (for 5/8 drill)
†
† Required for drilling floor.
1 Safety Goggles
‡
‡ Safety requirement when floor drilling.
1 406902049 Anchor Setting Tool (for drop-in anchors)
**
** Required for setting drop-in anchors.
1 3/4” Torque Wrench (25 ft.-lbs for 1/2 bolt)
††
†† Required for proper anchor nut torque.
1 Rope and 5/8-11-inch eye bolt
‡‡
‡‡ Accessories for uprighting bay if other means of lifting not available
1Level
***
*** Required during bay alignment
