 Issue 5 November 2000
363-206-208
Stand-Alone (Local) Installation Tests for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 6-3 DDM-2000 OC-12 Miscellaneous Discrete Connections
Name Mode ID Conn. Term Color
Output Common - J67 24 BK-BL
Miscellaneous Output - #1 output1 23 R-S
Miscellaneous Output - #2 output2 12 O-BK
Miscellaneous Output - #3 output3 11 BL-BK
Miscellaneous Output - #4 output4 10 S-R
Miscellaneous Output - #5 output5 17 W-BR
Miscellaneous Output - #6 output6 16 W-G
Miscellaneous Output - #7 output7 15 W-O
Miscellaneous Output - #8 output8 14 W-BL
Miscellaneous Output - #9 output9 8 G-R
Miscellaneous Output - #10 output10 7 O-R
Miscellaneous Output - #11 output11 6 BL-R
Miscellaneous Output - #12 output12 5 S-W
Miscellaneous Output - #13 output13 4 BR-W
Miscellaneous Output - #14 output14 3 G-W
Miscellaneous Output - #15 output15 2 O-W
Table 6-3 Notes:
1. Miscellaneous Output #11 through #15 are not available in Releases 5 and 7 software.
2. For each Miscellaneous Discrete connection, a pair of leads is connected between the
Miscellaneous Output point and the Output Common.
