Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Stand-Alone (Local) Installation Tests for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Tools, Test Sets, and Accessories
The following items are required:
Quantity Description Comcode
1 Electrostatic discharge wrist strap
*
* A wrist strap must be worn when handling circuit packs. Use the ESD jack provided on the user panel.
901011320
3 per BBG11B
or BBG12B
DSX-3 or STSX loopback cables
†
† Only required if the DDM-2000 OC-12 is cabled to a DSX-3 or STSX cross-connect.
1 ASCII Terminal or PC (personal computer) configured as
a terminal
1 per 23G-U
OLIU
15 dB Universal LBO
(Type dependent on type of fiber con-
nection desired)
LBO Type
ST 106795388
SC 106708985
FC/PC 106795438
1 per
23H-U
OLIU
20 dB Universal LBO
(Type dependent on type of fiber con-
nection desired)
ST 106795396
SC 106708993
FC/PC 106795446
1 per
23G-U, 23H-U
or 21G3-U
OLIU
Singlemode optical fiber cable
(Type dependent on Universal LBO
type used)
Fiber Type
ST-ST 105357727
SC-SC 106908247
FC/PC-FC/PC 106593825
1 per
21D-U
OLIU
Multimode optical fiber cable
(Type dependent on Universal LBO
type used)
ST-ST 105351795
SC-SC 106908668
FC-FC 107095549
