Issue 5 November 2000
363-206-208
End-To-End Installation Tests for Ring Applications of the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Fiber Connection
(1) After the appropriate optical power measurement is achieved, connect this
receive fiber to the MAIN-B-1 23-type OLIU IN (receive) connector at the node
where the power measurement is being taken.
NOTE:
In ring applications, the MAIN-B-1 OLIU transmit connects to the MAIN-B-2 OLIU
receive connector at the preceding node in the ring. Likewise, the MAIN-B-2
OLIU transmit connects to the MAIN-B-1 OLIU receive connector of the succeed-
ing node in the ring. This pattern remains true for each node throughout the ring.
(2) At this same node, connect the optical fiber transmit cable, that is to transmit in
the counterclockwise direction of the ring, to the DDM-2000 OC-12 23-type
MAIN-B-1 OLIU OUT connection and fully insert the OLIU into the shelf.
(3) Back at the first node, measure the optical power of the optical fiber receive
cable (this is the same fiber connected to the OLIU OUT in the previous step)
using the optical power meter.
(4) After the required optical power measurement is achieved, by adding the appro-
priate buildout, connect this receive fiber to the MAIN-B-2 23-type OLIU IN
(receive) connector at the node where the power measurement is being taken.
(5) Verify that, after a few moments, no alarms are present (that is, no FAULT LED
lighted on any circuit pack). If alarms are present, press the UPD/INIT push-but-
ton on the SYSCTL. If alarms do not clear, refer to the “Troubleshooting” section
of this manual.
Provision the Network Element
(1) For Release 5 shelves, enter the set-ne command.
Table 7-1 Lightguide Buildout Assemblies
Loss(dB)
23G-U or 23H-U OLIU
ST
®
Type SC Type
Code Comcode Code Comcode Code Comcode
0 A3070 106795354 A3060 106708951 A3080 106795404
5 A3070B 106795362 A3060B 106708969 A3080B 106795412
10 A3070D 106795370 A3060D 106708977 A3080D 106795420
15 A3070F 106795388 A3060F 106708985 A3080F 106795438
20 A3070H 106795396 A3060H 106708993 A3080H 106795446
