Lucent Technologies DDM-2000 OC-12 Installation Manual

 Issue 5 November 2000
363-206-208
Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 2-1 Discontinued Availability (D.A.) DS3 Cable Assemblies (see Note 1)
Application
(Note 2)
ED-8C727-20
Group
Cable Length (ft.)
(Note 3)
Cable Type
(Note 3)
Other End
Connector (Note 5)
To DSX-3
or
FT-2000
OC-48*
100 (D.A.) 150 1735006A
KS-23558,L6 BNC
101 (D.A.) 250 (max.)
103 (D.A.) 150 735A
104 (D.A.) 250 (max.)
106 (D.A.) 150 KS-19224, L2 KS-23558,L4 BNC
107 (D.A.) 150 (max.)
109 (D.A.) 450 (max.) 734A/735A KS-23558,L5 BNC
110 (D.A.) 450 (max.) 734A
To DACS III
-2000
120 (D.A.) 150 1735006A
9821AE
121 (D.A.) 500 (max.)
123 (D.A.) 150 735A
124 (D.A.) 500 (max.)
126 (D.A.) 900 (max.) 734A/735A †
To DACS IV
-2000
130 (D.A.) 150 1735006A
9821EA &
9821FA
131 (D.A.) 500 (max.)
133 (D.A.) 150 735A
134 (D.A.) 500 (max.)
136 (D.A.) 900 (max.) 734A/735A ‡
