Lucent Technologies DDM-2000 OC-12 - Page 97

Issue 5 November 2000 
363-206-208
Equipment and Rear Access Cabling for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
Table 2-1 Notes:
1. Discontinued Availability means cable can no longer ordered.
2. All the DS3 cable assemblies can be used for any muldem. DDM-2000 OC-12 DS3 backplane connec-
tors are J30-J35 (for muldem A), J36-J41 (for muldem B), J42-J47 (for muldem C), and J48-J53 (for mul-
dem D).
3. Cable lengths are specified by the customer for all cables designated as having a (max.) length. All other
cable lengths are fixed.
4. A 1735006A six conductor cable provides three DS3 IN and three DS3 OUT cables to accommodate one
full muldem on the DDM-2000 OC-12 shelf. 734A, 735A, and KS-19224, L2 cables provide one DS3 IN
cable and one DS3 OUT cable to accommodate a partially equipped muldem.
5. All the Group 100 to 136 cables have a BNC KS-23558, L6 connector on one end except the following:
Groups 106 and 107 cables have a BNC KS-23558, L4 connector on one end. The Group 110 cable has
a BNC KS-23626, L5 (right angle) connector on one end.
* For cables going to DACS III-2000 and DACS IV-2000 equipped with a BNC I/O panel, cable lengths
designated as 250 (max.) and 450 (max.) become 500 (max.) and 900 (max.), respectively.
† The Group 126 cable consists of two 734A cables (1-900 feet) with a BNC connector on one end and no
connector on the other end. This group also includes two 13-foot 735A cables with a 219P connector on
one end and a ED-7G001-23, Group 204 cable assembly on the other end. The 735A cable will have to
be spliced to the 734A cable per the 219P connector.
‡ The Group 136 cable consists of two 734A cables (1-900 feet) with a BNC connector on one end and no
connector on the other end. This group also includes two 13-foot 735A cables with a 219P connector on
one end and a 9821EA or 9821FA connector on the other end. The 735A cable will have to be spliced to
the 734A cable per the 219P connector.
Table 2-1 Discontinued Availability (D.A.) DS3 Cable Assemblies (see Note 1) (Continued)
Application
(Note 2)
ED-8C727-20
Group
Cable Length (ft.)
(Note 3)
Cable Type
(Note 3)
Other End
Connector (Note 5)
