Lucent Technologies DDM-2000 OC-12 Installation Manual

Issue 5 November 2000 
363-206-208
Powering, Verification, and Circuit Pack Installation for the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
BBG5 SYSCTL Option Notes :
1. The SYSCTL has four option switches which must be properly set. Refer to the option switch
settings on the following two pages.
2. All switches should be set per the customers engineering records.
3. In the absence of engineering records, refer to Figure 5-1 on page 5-15.
Figure 5-3. BBG5 SYSCTL Option Switches (Sheet 1 of 4)
Component Side
Connector
Edge
S3
S2
S4
ON
OFF
ON
21
ON
OFF
ON
87654321
ON
OFF
ON
87654321
S1
ON
S4
OFF
ON
87654321
S3
S2
S1
