End-To-End Installation Tests for Ring Applications of the DDM-2000 OC-12 Multiplexer
Lucent Technologies - Proprietary
See Notice on first page
(4) For Release 5 applications, issue the rtrv-fecom; command to verify User Side
(us) and Network Side (ns) settings for each address occupied by an OLIU per
the following table:
If settings differ from the default values shown in the table, use the
set-fecom
command to change them to the values shown.
NOTE:
User Side (us) and Network Side (ns) settings for DDM-2000 OC-3 shelves, opti-
cally connected to the OC-12 shelf function units, must be set as follows:
(5) Enable Far End Communications for the Main-B-2 OLIU at the first node using
the
set-fecom:dcc-mb2:com=enabled; command.
If this shelf has function unit OLIUs that have previously been optically con-
nected to DDM-2000 OC-3 shelves, enable communications between those
shelves also as follows:
Issue the
set-fecom:dcc- address :com=enabled; command at the OC-12 shelf
for the function unit addresses of those OLIUs, and then at the OC-3 shelf for the
Main OLIU addresses.
Address US/NS Setting
dcc-mb1 us
dcc-mb2 ns
0x1
Applications
1+1
Applications
dcc-a1 dcc-a ns
dcc-a2 - us
dcc-b1 dcc-b ns
dcc-b2 - us
dcc-c1 dcc-c ns
dcc-c2 - us
dcc-d1 dcc-d ns
dcc-d2 - us
Address
US/NS Setting
OC-3 Release 8
OC-3 Release 7 or
9
dcc-m dcc-m1 us
dcc-m2 ns
dcc-a dcc-a ns
dcc-b dcc-b ns
dcc-c dcc-c ns
