Data Collection
Data Collection
Start | Settings | System | Data Collection
Set scanner/imager keyboard wedge parameters, enable or disable symbologies from being scanned, scanner icon
appearance, active scanner port, and scan key settings. Assign baud rate, parity, stop bits and data bits for available COM
ports. Scanner parameters apply to the MX7 Tecton integrated scanner/imager only. Barcode manipulation parameters apply to
barcodes scanned by the MX7 Tecton integrated scanner/imager engine.
Scanner configuration can be changed using the Data Collection settings panels or via the LXE API functions. While the
changed configuration is being read, the Scanner LED is solid amber. The scanner is not operational during the configuration
update.
Important. When returning scanner or imager to factory default settings: After scanning the scanner-engine-specific barcode
to reset all scanner parameters to factory default settings (i.e. Reset All, Set Factory Defaults, Default Settings, etc.), the
next step is to open the Data Collection settings panel. Tap ok and close the Data Collection panel. This action will
synchronize all scanner formats. Programming barcodes are available in the Integrated Scanner Programming Guide.
The MX7 Tecton has one integrated barcode scanner/imager port. Only one scan engine is installed at a time. Scan engines
are not “hot swappable”. The MX7 Tecton may have one of three Symbol laser scan engines:
l Short Range Laser Scanner, 955I
l Low Power Scanner, 955E
l Multi-Range "LORAX" Laser, 1524ER
or a Hand Held Products 2D Area Imager, 5300.
Note: Low Power Scanner, 955E does not support aim mode. Any attempt to adjust the aiming beam using SE955
programming barcodes will fail. The Low Power scanner does not decode Codablock, Code93i, Matrix 2 of 5 or Telepen
symbologies.
The integrated scan engine activates when the Scan button on the front of the MX7 Tecton is depressed or when the trigger on
an installed trigger handle is depressed.
Symbol scanner:
Please refer to the Integrated Scanner Programming Guide for instruction on configuring specific scanner/imager parameters
by using the MX7 Tecton to scan engine-specific setup barcodes in the guide.
HHP Imager:
Use the (Hand Held Properties) HHP Properties button on the Data Options tab and the Advanced button available on many of
the individual Symbology Settings screen to configure the HHP Imager. There are no configuration barcodes for this imager.
